Serving Open-Source LLMs with vLLM on Kubernetes

Running an LLM in a notebook is easy. Running it in production with predictable latency, sane GPU costs, and safe deployments is where the real work starts.

For most teams serving open-source models, vLLM + Kubernetes is one of the best current defaults. vLLM gives you efficient inference with paged attention and continuous batching. Kubernetes gives you scheduling, autoscaling, rollout controls, and operational consistency with the rest of your platform.

The mistake is treating LLM serving like a normal stateless web service. It isn't. Cold starts are expensive, VRAM is the real bottleneck, and bad routing decisions can destroy latency under load.

Here's the production playbook we use.

Why vLLM Works Well in Production

Compared to a naive Hugging Face server, vLLM is designed for throughput:

• Continuous batching improves GPU utilization under concurrent traffic
• Paged attention reduces KV cache waste
• OpenAI-compatible APIs make client integration simpler
• Tensor parallel support helps when a model doesn't fit on one GPU

That doesn't mean you can just deploy it and walk away. You still need to answer:

• Which model belongs on which GPU class?
• How do you handle context length explosions?
• When do you scale replicas vs scale up GPU size?
• How do you roll out a new model without breaking production traffic?

Step 1: Right-Size the Model to the GPU

Most serving instability starts with bad sizing assumptions.

Teams often choose a model first, then try to force it onto whatever GPU they already have. The better order is:

1. Define latency and throughput targets
2. Define the maximum prompt + completion length
3. Estimate KV cache growth under concurrency
4. Choose the smallest GPU shape that meets those targets with headroom

As a rough rule:

If you don't know your real concurrency profile, measure it before production. LLM systems fail because teams size for average traffic while users generate bursty, long-context requests.

Step 2: Set Explicit Runtime Limits

Unlimited generation is not a feature. It's a denial-of-service vector against your own GPUs.

At minimum, enforce:

• Maximum prompt tokens
• Maximum completion tokens
• Maximum concurrent requests per pod
• Request timeout
• Queue depth limit

# kubernetes/vllm-deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: llama3-vllm
spec:
  replicas: 2
  strategy:
    rollingUpdate:
      maxUnavailable: 0
      maxSurge: 1
  template:
    spec:
      nodeSelector:
        workload: gpu-inference
      containers:
        - name: vllm
          image: vllm/vllm-openai:latest
          args:
            - --model
            - meta-llama/Meta-Llama-3-8B-Instruct
            - --dtype
            - bfloat16
            - --max-model-len
            - "8192"
            - --gpu-memory-utilization
            - "0.9"
            - --max-num-seqs
            - "32"
          ports:
            - containerPort: 8000
          resources:
            requests:
              cpu: "4"
              memory: "24Gi"
              nvidia.com/gpu: "1"
            limits:
              cpu: "8"
              memory: "32Gi"
              nvidia.com/gpu: "1"
          readinessProbe:
            httpGet:
              path: /health
              port: 8000
            initialDelaySeconds: 45
            periodSeconds: 10
          livenessProbe:
            httpGet:
              path: /health
              port: 8000
            initialDelaySeconds: 90
            periodSeconds: 20

Two practical notes:

• Readiness delay must reflect model load time. Otherwise Kubernetes routes traffic before the model is actually usable.
• gpu-memory-utilization should leave safety margin. Running at 100% VRAM works until a slightly longer prompt arrives and crashes the pod.

Step 3: Put a Gateway in Front of the Model

Do not let every client talk directly to vLLM pods.

A gateway layer gives you:

• Authentication and rate limiting
• Per-tenant quotas
• Request validation
• Model routing
• Fallback logic
• Centralized logging

Without that layer, your model server becomes your API gateway, your multi-tenant control plane, and your abuse boundary all at once. That's the wrong abstraction.

# gateway/router.py
class LLMRouter:
    def __init__(self, backends):
        self.backends = backends

    def route(self, request):
        prompt_tokens = estimate_tokens(request.messages)

        if prompt_tokens > 6000:
            raise ValueError("Prompt exceeds allowed context window")

        if request.tier == "internal-tools":
            return self.backends["fast-8b"]

        if request.requires_json:
            return self.backends["strict-json-model"]

        if request.quality == "high":
            return self.backends["large-reasoning-model"]

        return self.backends["default-8b"]

The gateway is also where you should enforce hard protections:

• reject oversized requests early
• normalize stop sequences
• strip unsupported parameters
• log token counts before the call hits the GPU

Step 4: Autoscale on Queue Pressure, Not CPU

CPU is the wrong signal for most LLM serving systems. GPU-bound inference pods can show low CPU while request latency is getting worse.

Better scaling signals:

• in-flight requests
• queue depth
• tokens generated per second
• p95 latency
• GPU utilization

If you're using KEDA or a custom metrics adapter, scale on demand signals that match user pain.

# keda/scaledobject.yaml
apiVersion: keda.sh/v1alpha1
kind: ScaledObject
metadata:
  name: vllm-scaler
spec:
  scaleTargetRef:
    name: llama3-vllm
  minReplicaCount: 2
  maxReplicaCount: 8
  triggers:
    - type: prometheus
      metadata:
        serverAddress: http://prometheus.monitoring:9090
        metricName: vllm_active_requests
        threshold: "24"
        query: sum(vllm_active_requests{deployment="llama3-vllm"})

Also keep in mind: autoscaling GPU workloads is slower than CPU web services because new replicas need time to pull weights and warm the model. If you wait until the queue is already red, users will still feel the spike.

Step 5: Separate Interactive and Batch Traffic

If embeddings, eval jobs, offline summarization, and chat requests all share the same deployment, your latency will look random.

Split workloads by behavior:

• Interactive serving for user-facing chat and copilots
• Batch serving for offline enrichment and nightly jobs
• Experimental serving for internal testing and prompt evaluation

That separation gives you sane SLOs. A batch job can tolerate a queue. A chat product usually can't.

Step 6: Roll Out Models Like Application Releases

Many teams still replace one model with another and hope for the best. That's not a rollout plan.

Use staged promotion:

1. Load the new model in a parallel deployment
2. Send shadow traffic or internal traffic first
3. Compare latency, refusal rate, output quality, and error rate
4. Shift 5%, then 25%, then 100%
5. Keep a rollback path ready

# istio/virtualservice.yaml
http:
  - route:
      - destination:
          host: llm-serving
          subset: stable
        weight: 90
      - destination:
          host: llm-serving
          subset: canary
        weight: 10

Track more than uptime during rollout. A model can be perfectly available and still worse for the business because:

• outputs are lower quality
• latency regresses at longer context lengths
• prompt formatting breaks tool calls
• JSON mode becomes unreliable

Step 7: Monitor the Metrics That Actually Matter

The minimum dashboard for LLM serving should include:

• request count and error rate
• p50/p95 latency
• tokens in and tokens out
• queue depth
• GPU utilization
• OOM events
• model load duration
• per-tenant usage

And log enough context to answer operational questions later:

• which model handled the request
• prompt token count
• output token count
• request class
• timeout vs validation vs upstream failure

If you only monitor pod health, you'll miss the failure modes users actually see.

Common Production Mistakes

These show up repeatedly:

• Using one large model for every use case instead of routing by task
• No hard cap on context length, which turns occasional long prompts into VRAM incidents
• Scaling on CPU while queue depth and latency explode
• No gateway layer, so rate limiting and policy enforcement are bolted on later
• No warm capacity, causing cold-start storms during traffic spikes

A Sensible Starting Architecture

If you're building from scratch, start here:

• one gateway service
• one primary instruct model on vLLM
• one smaller fallback model
• dedicated GPU node pool for inference
• Prometheus + Grafana metrics
• canary routing for model upgrades

That is enough for many teams to reach production safely. You do not need a giant LLM platform on day one.

The real objective is not maximum sophistication. It's predictable behavior under load.

Final Takeaway

vLLM + Kubernetes is a strong production default because it gives you performance and operational control. But the value comes from the system around the model: sizing, routing, protection, rollout, and observability.

Treat LLM serving as infrastructure, not as a demo wrapper around a model. The teams that do that early avoid most of the painful failures later.
